Description
. . . . . The White-Rodgers 3F01-160 is a 3/4" fixed-setting snap disc fan control. The 3F01 series are fixed-setting snap disc fan controls used to switch a furnace, blower or ventilation fan on and off from air temperature. They mount directly in the airstream and need no calibration - the disc snaps closed on temperature rise and opens again on fall.
Features (per White-Rodgers catalog):
* Designed for quick on-job replacement
* Easy to remember type numbers - "L" for Limit, "F" for Fan
* Last three numbers indicate cut-out temperatures on limits and cut-in temperatures on fan controls
* Mounting holes match standard 3/4" snap discs
* Tab-to-screw terminal adapters furnished
Specifications:
* Temperature Rating: 160°F cut-in
* Type: Snap disc fan control, fixed setting
* Switch Type: SPST, close on rise
* Reset: Automatic
* Mounting: 3/4" flanged airstream mount
* Voltage Rating: 120/240 VAC (full load); 120/240/277 VAC (resistive / pilot duty)
* Current Rating: 10 A at 120 VAC, 5 A at 240 VAC (full load); 25 A at 120/240 VAC, 21.6 A at 277 VAC (resistive)
* Power Rating: 125 VA at 120/240/277 VAC (pilot duty)
* Max Ambient: 350°F
Accessory: If an adapter plate is required for the application, White-Rodgers F6-1798 must be purchased separately.
Application: Gas and oil furnace fan/blower switching, unit heaters, wood and pellet stove blowers, solar air heaters, and general ventilation and heat-management duty.
Brand: White-Rodgers (Emerson Electric Co. / Copeland)
Model / Part Number: 3F01-160
Product Type: Snap Disc Fan Control
Condition: New
Note: Differential / cut-out temperature for the -160 suffix was not located in OEM literature; verify against the control label before publishing.. White-Rodgers. Emerson. 3F01-160.
