Name: Johnson Controls D-3153-40 Pneumatic Damper Actuator [New]
Brand: Johnson Controls
SKU: B2E-LFX-168690
Price: 417.57 USD
Availability: InStock

Description

. . . . . This item is a Johnson Controls D-3153-40 pneumatic piston damper actuator.

The D-3153 is a multipurpose positioning device used to operate ventilating dampers in response to the output of a pneumatic controller or electro-pneumatic transducer. Air pressure from the controller acts on the actuator diaphragm, driving the piston against the internal spring and the load. The series handles dampers up to 16 square feet for proportional volume control and 25 square feet for two-position actuation, with 0 to 20 psig normal HVAC control air; construction is all-aluminium with a 2-way swivel head and a telescoping piston rod reaching attachment points up to 8-3/4 in. (222 mm) from the actuator face.

Specification note: Johnson Controls' ordering table for this series lists the D-3153-1, -2, -3, -4, -5, -6, -7 and -18 actuator models, plus the -6001/-6002/-6003 body-only codes. The -40 suffix is not among them, so we cannot state the spring range or mounting bracket configuration - and since spring range determines the control band, please confirm it before ordering and we will verify the model.

* Brand / Manufacturer: Johnson Controls
* Model / Part Number: D-3153-40
* Series: D-3153 / D-3000 Series pneumatic damper actuators
* Product Type: Pneumatic piston damper actuator
* Spring Range: Not established - please confirm
* Mounting Bracket: Not established - please confirm
* Maximum Damper Area: 16 sq ft proportional, 25 sq ft two-position (series specification)
* Control Air Pressure: 0 to 20 psig (normal HVAC)
* Documented Series Models: D-3153-1, -2, -3, -4, -5, -6, -7, -18; -6001/-6002/-6003 (body only)

Typical applications include outdoor air, return air and mixing box damper control on air handling units, and ventilating damper control on pneumatic systems. Please confirm the spring range required. Field repairs must not be made; contact Johnson Controls for a replacement body.. Johnson Controls. Johnson Controls. D-3153-40.
