Name: Johnson Controls AV-C10A-601R V11 Air Valve Coil, 24V [New]
Brand: Johnson Controls
SKU: B2E-TRO-20539
Price: 43.71 USD
Availability: InStock

Description

. . . . . The Johnson Controls AVC10A-601R is a replacement solenoid coil for the V11 Series Three-Way Solenoid Air Valve, rated 24 V, 50/60 Hz. Coil replacement is the only field repair Johnson Controls permits on a V11 valve, and the replacement coil is supplied complete with a cover and nameplate.

V11 Series three-way solenoid air valves are used where the operation of a pneumatically operated device depends on an electrical circuit. In a typical application supply air is connected to the normally closed port and the controlled device to the common port. When the coil is energized, a magnetic field lifts a plunger-type valve stem and supply air is directed to the device; when the coil is de-energized the supply connection closes and the normally open port exhausts air from the device. Reverse action is obtained by connecting supply air to the normally open port instead. The coil is fitted with 18 inch wire leads brought out through a 7/8 inch conduit opening in the end of the valve case, and splices should be made with approved solderless connectors or soldered and taped. Check the voltage on the valve data plate against the supply before installing, and observe at least three complete operating cycles after replacing a coil.

* Brand / Manufacturer: Johnson Controls
* Model / Part Number: AVC10A-601R
* Series: V11 Series Three-Way Solenoid Air Valve replacement parts
* Product Type: Replacement solenoid coil
* Coil Voltage: 24 V, 50/60 Hz
* Supplied With: Cover and nameplate
* Lead Wires: 18 in.
* Conduit Opening: 7/8 in. diameter in end of case
* Valve Temperature Rating: 60°C maximum
* Related Coil Voltages: AVC10A-600R (110/120 V), -602R (208 V), -603R (220/240 V), -609R (24 VDC), -610R (277 V), -611R (440/480 V), -612R (550/600 V)

Typical applications include re-coiling V11 three-way solenoid air valves that switch pneumatic actuators, damper operators and pneumatic control devices from 24 VAC control circuits, the most common control voltage on Metasys and other building automation systems.. Johnson Controls. Johnson Controls. AV-C10A-601R.
