Name: Honeywell XFU830A Panel Bus Mixed I/O Module, 34 I/O [New]
Brand: Honeywell
SKU: B2E-LFX-166583
Price: 704.67 USD
Availability: InStock

Description

The Honeywell XFU830A is a Panel Bus Mixed I/O Module with screw terminals for the Honeywell Excel 800 system and the Honeywell CIPer 50 controller. It provides 34 I/O points in a single module: 8 analog inputs, 8 analog outputs, 12 binary inputs and 6 relay outputs.

Unlike the pluggable Panel Bus modules, the mixed I/O modules have an integrated socket - a separate terminal socket is not required, which reduces part count and installation time on larger panels.

Honeywell states that all Excel 800 I/O modules, pluggable and mixed, are protected against short circuit and against 24 Vac +20% and 30 Vdc. Addressing is performed using a HEX switch, a status LED aids fault diagnosis, and outputs have a configurable safety position for loss of communication with the controller. The relay outputs are rated for up to 3 A resistive or inductive load per the Excel 800 documentation.

* Brand / Manufacturer: Honeywell
* Model Number: XFU830A
* System: Excel 800 Panel Bus; compatible with CIPer 50 controller
* Product Type: Mixed I/O module with screw terminals and integrated socket
* Total I/O: 34 points
* Analog Inputs: 8
* Analog Outputs: 8
* Binary Inputs: 12
* Relay Outputs: 6
* Terminal Type: Screw terminals, integrated socket (no separate terminal socket required)
* Protection: Short circuit protected; protected against 24 Vac +20% and 30 Vdc
* Addressing: HEX switch
* Fail Behaviour: Configurable safety position on loss of controller communication
* Optional Accessories: XS830 and XS831 Auxiliary Terminal Packages (for mixed I/O modules only); auxiliary terminal blocks for 0-20 mA signal connection

Typical applications include compact Excel 800 or CIPer 50 panels where a high point count is needed in minimal DIN rail space.

Important sensor limitation: Honeywell notes that the mixed Panel Bus I/O modules XF830A, XFU830A and CPO-IO830 have inputs suitable only for signals from NTC20kΩ sensors and 0/2...10 V, 0/4...20 mA sources - unlike the pluggable modules, which support a wider sensor range including NTC10k, PT1000, Johnson A99 PTC, NI1000TK5000, PT3000 and Balco500. The mixed modules also have non-configurable binary input LEDs. If your application uses PT1000 or other non-NTC20k sensors, a pluggable module is required instead.. Honeywell. Honeywell. XFU830A.
