Description
CAT.NO.: VM3534, SPEC.: 34A63-884. HP: .33, VOLTS: 230/460, AMP: 1.6/.8, HZ: 60, PH: 3. RPM: 1725: FRAME: 56C, SER.F.: 1.35, CODE: M, DES: B, CLASS: B. NEMA-NOM-EFF: 68, PF: 57, RATING: 40C AMB-CONT. CC: USABLE AT 208V 1.9, DE: 6203, ODE: 6203, ENCL: TEFC SN, SFA: 1.8/.9, NP1256L. Ball bearings with a locked drive end bearing and heavy-gauge steel or cast iron frame. Super-E?é?« motors have NEMA Premium efficiency. Applications: Pumps, fans, conveyors, machine tools, gear reducers and other applications requiring a NEMA C-face motor.. Baldor. Baldor Electric. VM3534.
