Allen-Bradley 800F-MX01 22mm Contact Block 1 N.C.

The Allen-Bradley 800F-MX01 is a contact block from the Bulletin 800F 22 mm push button range, with a single normally closed contact. A normally closed block is the stop-circuit element of a control station: it is held closed by the operator at rest and opens when the button is pressed, so a broken wire or a failed contact stops the machine rather than silently disabling the stop function.

Rockwell's 22 mm contact-code convention is documented in the Push Button Selection Guide, where X10 denotes one normally open contact and X01 one normally closed - the same reading applied here.

Specifications:

* Family: Bulletin 800F 22 mm push buttons
* Type: Contact block
* Contacts: 1 N.C. (per the X01 code convention)
* Panel Cutout: 22 mm
* Model / Part Number: 800F-MX01

Brand: Allen-Bradley
Manufacturer: Rockwell Automation
Model / Part Number: 800F-MX01
Product Type: 22 mm Contact Block, 1 N.C.
Condition: New

Note: The X01 = 1 N.C. reading is documented in the Rockwell 22 mm Push Button Selection Guide for the 800E series and applied here by convention; no listing for 800F-MX01 specifically was located. The M designation and the contact current and voltage ratings are unverified.
