. . . . . The Allen-Bradley 800E-3DL5 is a back-of-panel light module from the Bulletin 800E 22 mm pilot device range: 3-across mounting, incandescent, 120V AC/DC. Rockwell Automation's 22 mm Push Button Selection Guide lists it directly in the light module table opposite its 2-across counterpart, the 800E-2DL5.
The 2-across versus 3-across distinction is a circuit capacity limit, not just a physical one. Rockwell's guide notes 2-across mounting supports up to five circuits and 3-across up to four for this style, so the mounting choice determines how many blocks can be stacked behind a single operator before the assembly runs out of room.
Bulletin 800E light module range (per the Rockwell Automation 22 mm Push Button Selection Guide):
* No lamp - 800E-2DL0 (2-across), 800E-3DL0 (3-across)
* Incandescent 24V AC/DC - 800E-2DL3, 800E-3DL3
* Incandescent 120V AC/DC - 800E-2DL5, 800E-3DL5
* Integrated LED module (red) - 800E-3NL3R (24V AC/DC), 800E-3NL5R (120V AC), 800E-3NL7R (240V AC)
* Contact blocks - 800E-2X10 / 3X10 (1 N.O.), 800E-2X01 / 3X01 (1 N.C.), 800E-2X10V / 3X10V (PenTUFF low voltage)
Specifications:
* Family: Bulletin 800E 22 mm pilot devices
* Type: Back-of-panel light module
* Mounting: 3-across
* Lamp: Incandescent
* Voltage: 120V AC/DC full voltage
* Model / Part Number: 800E-3DL5
Brand: Allen-Bradley
Manufacturer: Rockwell Automation
Model / Part Number: 800E-3DL5
Product Type: 22 mm Light Module, 120V, 3-Across
Condition: New. Allen-Bradley. Rockwell Automation. 800E-3DL5.
