  • Veris H8163-1600-4-3 Revenue Grade Power Meter, 3x 1600A Large CT [Refurbished]

    • Veris H8163-1600-4-3 Revenue Grade Power Meter, 3x 1600A Large CT [Refurbished]

    Veris

    $1,475.52
    Write a Review
    SKU:
    B2E-TRO-26468
    Availability:
    In Stock - Ships Immediately
    Shipping:
    Calculated at Checkout
    Adding to cart… category.add_cart_announcement

    Product Description

    . . . . . Commercial Energy Meter for 120-480V with Pulse Output and Phase Loss Alarm - 3x 1600A Large Current Transformers.

    The H81xx Series Energy Meters are easy to install and provide exceptional system accuracy, making them ideal for all submetering applications.

    Each meter is factory-matched with one to three split-core CTs. The meter/CT pairs are system-calibrated to provide excellent total system accuracies of 1% from 2% to 100% of the amperage rating of the CTs (e.g., 2-100 amps with 100 amp CTs). Matching serial numbers assure that the meter and CT were calibrated together (matching does not apply if using 100A CTs).

    The H81xx is easy to install. The split-core CTs eliminate the need to remove electrical conductors, reducing installation time. The meter is also capable of detecting and correcting phase reversal, eliminating the need for concern about CT load orientation. The convenient color coding of the CTs and voltage leads make correct connection simple.

    Features
    Revenue Grade measurements
    High resolution backlit LCD display provides clear readings at a distance... reduces the risk of misinterpretation of the data. Back-lighting can be disabled if desired
    H8163 provides a pulse output from 1/10 to 1 pulse per kWh for easy connection to existing control or data acquisition systems
    Provides a phase-loss alarm... protects equipment (H8163)
    With the optional communications board (H81xx-CB), the H81xx can easily be added to a Modbus, BACnet or N2 control system network to report multiple variables including kW, kWh, kVAR, PF, Amps and Volts, providing crucial power information at a reduced installation cost
    Split-core CTs eliminate the need to remove electrical conductors...reduces installation time
    Energy meters automatically detect and correct phase reversal, eliminating the need to be concerned with CT load orientation
    CTs and voltage leads are color coded making it easy to determine correct connection

    Applications
    Commercial Tenant Submetering
    Performance Contracting
    Allocating Costs
    Real-Time Power Monitoring Via Local Display or Through Control/Data Acquisition Systems. Veris. Veris Industries. H8163-1600-4-3.
