Proportional Damper Actuator. Spring Return Fail-Safe. 24 V for 2 to 10 VDC and 4 to 20 mA Control Signal. Output Signal of 2 to 10 VDC for Position Indication. Torque Min. 133 in-lb, for Control of Air Dampers. Application - For proportional modulation of dampers in HVAC systems. Actuator sizing should be done in accordance with the damper manufacturer?ó?é¼?äós specifications. The actuator is mounted directly to a damper shaft up to 1.05?ó?é¼?¥ in diameter by means of its universal clamp. A crankarm and several mounting brackets are available for applications where the actuator cannot be direct coupled to the damper shaft. The actuator operates in response to a 2 to 10 VDC, with the addition of a 500?ó"?ª resistor, a 4 to 20 mA control input from an electronic controller or positioner. A 2 to 10 VDC feedback signal is provided for position indication or master-slave applications. Operation - The AF series actuators provide true spring return operation for reliable fail-safe application and positive close-off on air tight dampers. The spring return system provides constant torque to the damper with, and without, power applied to the actuator. The AF series provides 95?é?? of rotation and is provided with a graduated position indicator showing 0 to 95?é??. The AF has a unique manual positioning mechanism which allows the setting of any damper position within its 95?é?? of rotation. The actuator is shipped at +5?é?? position (5?é?? from full fail-safe) to provide automatic compression against damper gaskets for tight shut-off. When power is applied, the manual mechanism is released and the actuator drives toward the full fail-safe position. The actuator will memorize the angle where it stops rotating and use this point for its zero position for its normal control operations. The manual override can also be released physically by the use of a crank supplied with the actuator. The AF uses a brushless DC motor which is controlled by an Application Specific Integrated Circuit (ASIC) and a microprocessor. The microprocessor provides the intelligence to the ASIC to provide a constant rotation rate and to know the actuator?ó?é¼?äós exact zero position. The ASIC monitors and controls the brushless DC motor?ó?é¼?äós rotation and provides a digital rotation sensing function to prevent damage to the actuator in a stall condition. The actuator may be stalled anywhere in its normal rotation without the need of mechanical end switches.. Belimo. Belimo. AF24-SR US.
